KD1814-S1-C Vision Laser Cutting Machine With Safe Cover

KASU Laser’s single-head vision laser cutting machine with a top Canon camera can cut printed or embroidered textiles with super high precision and production.

And the all-around safety cover model is specially designed to meet the government requirements for plant safety.

  • All-Round Safe Cover Meet Compliance Requirements
  • Powerful Vision Software Automate Your Factory
  • Both Vison and Non-Vision Working Modes
  • Low Initial Machine Investment, More Profits
High Cutting Precision
Hot Sealed Cutting Edge
Any Type of Textiles
Continuous Working Mode

Vision Laser Cutting Machine Solution

Co2 laser cutting technology is ideal enough to smoothly and effectively cut many kinds of textiles without causing any harm overall.

The KD1814-S1-C Vision Laser Cutting Machine With Safe Cover is the laser cutting machine combined with the advanced top vision software system of the KASU laser. It can automatically recognize the contour of the printed or embroidered fabrics, leather, and other flexible materials and then cut with super high accuracy and efficiency.

Video Cover
Working Area 1800MM*1400MM Software KASU
Laser Type Glass CO2 Laser Tube Working Speed <1000 MM/S
Laser Power 80/100/130/150W Power Supply Requirements AC220V±5%   50Hz/60Hz 1Phase
Heads of Laser Single Head Format Supported AI\BMP\PLT\DXF\DST
Dimensions with Wood Package 2.28*2.5*2.14M  2.24*1.55*1.16M Positioning Accuracy ±0.1MM
Gross Weight 1400KG Operating Temperature minus 10℃~45℃
Motion System Stepping Motor Operating Humidity 5-95%
Cooling System 5000 Industrial Water Chiller Total Power <1.5KW (Excluding exhauster)



Self-Owned Top Vision Software System

KASU owns the full property of the large vision software system. Together with the Canon EOS Camera with 2,400 Mega Pixels, the KD1814-S1-C camera laser cutter’s vision software automates the whole graphic detection and position cutting process.

Top Vision Software for Laser Cutter With Camera
Auto Feeding Conveyor Belt

Auto Feeding Conveyor Table

KD1814-S1-C is equipped with a chain conveyor belt, which can auto-feed the roll material right after the laser cutting process. Together with the optional active feeder, the operator only needs to take care of the cut pattern pick-up job.

All-Round Safe Cover

We designed this specialized model based on some clients’ government compliance requirements. The all-around safe cover can enclose the whole cutting range. The laser cutter will stop the laser cutting head immediately if the cover is opened.

KASU LASER ALL ROUND SAFE COVER

Testimonial

What Our Clients Say About KASU Laser Cutter
  • Testimonial
    Abdulaziz Karimova
    Tashkent, Uzbekistan
    We purchased Kasu's vision laser cutting machine with a safe cover four years ago. They offer very fast lead time and fast delivery. Really appreciate KASU's dedication to helping my business grow. Thank you, KASU!
How KASU Support Your Business

How KASU Support Your Business

KASU Laser is a professional laser cutter manufacturer and supplier with over 12 years of experience. We have our own R&D center and have 70+ vision software and laser machine intelligent properties.

Our designer team can also customize machine models according to your special industry requirements. Message us!
