KD1814-S2 Double Head Laser Cutter With Camera
Under the non-vision cutting mode, the two heads of the KASU KD1814-S2 laser cutter can simultaneously cut the same shapes of patterns in plain fabrics. And when working under the vision mode, this model can also position cut graphics at a very high speed.
- Extreme Cutting Versatility
- Powerful Vision Software Meet Multi-Industry Needs
- Vision and Non-Vision Working Modes
- Stable and 24 Hours Running
- 🚚 7–15 days lead time
- 🛡 12-month warranty
High Cutting Precision
Hot Sealed Cutting Edge
Any Type of Textiles
Continuous Working Mode
See the KD1814-S2 Double Head Laser Cutter With Camera in Action — Vision-Aided Cutting Video
Watch the KD1814-S2 Double Head Laser Cutter With Camera run a real vision-aided cutting job on our factory floor — camera registration, smart path correction, and continuous output captured at production speed. The clip shows what to expect on day one before you commit to a machine of this class.
See the KD1814-S2 Double Head Laser Cutter With Camera in Action — Vision-Aided Cutting Video
Laser cutting technology is ideal enough to smoothly and effectively cut many kinds of materials without causing it any harm overall.
The KD1814-S2 Double Head Laser Cutter With Camera is the laser cutter combined with the advanced large vision software system of the KASU laser. It can automatically recognize the contour of the printed or embroidered fabrics, leather, and other flexible materials and then cut with super high accuracy and efficiency.
KD1814-S2 Double Head Laser Cutter With Camera — Vision System Specs, Accessories & Manufacturing
Every vision system, optics and motion dimension of the KD1814-S2 Double Head Laser Cutter With Camera in one place — complete technical data sheet, included accessories, available optional upgrades, and our factory manufacturing process. Key strengths at a glance: High Cutting Precision, Hot Sealed Cutting Edge, and Any Type of Textiles. Switch the tabs below to drill into each.
- Data Sheet
- Includes & Options
- Video Testimonials
| Working Area | 1800MM*1400MM | Software | KASU |
| Laser Type | Glass CO2 Laser Tube | Working Speed | <1000 MM/S |
| Laser Power | 80/100/130/150W | Power Supply Requirements | AC220V±5% 50Hz/60Hz 1Phase |
| Heads of Laser | Double Heads | Format Supported | AI\BMP\PLT\DXF\DST |
| Dimensions with Wood Package | 2.28*2.5*1.51M 2.28*0.86*0.55M | Positioning Accuracy | ±0.1MM |
| Gross Weight | 1150KG | Operating Temperature | minus 10℃~45℃ |
| Motion System | Stepping Motor | Operating Humidity | 5-95% |
| Cooling System | 5200 Industrial Water Chiller | Total Power | <1.5KW (Excluding exhauster) |
What's Included with the KD1814-S2 Double Head Laser Cutter With Camera
- 2× Glass CO2 laser tubes — 80W / 100W / 130W
- 2× independent cutting heads + side-mount CCD camera
- HIWIN-spec linear rails for 1800 × 1400 mm bed
- 2× American II–VI 25mm focusing lenses
- 2× three-mirror reflective sets
- S&A CW-5200 industrial chiller (2-tube)
- Hailey diaphragm air pump (2-line)
- 1.5kW centrifugal smoke exhaust + ducting kit
- Industrial DC HV power supply
- Triangle-truss steel frame
- Vision software
- E-stop + tower light
- Multi-language CE laser warning labels
- Factory tool kit
Compatible Upgrades for the KD1814-S2 Double Head Laser Cutter With Camera
- Upgrade to top-mount CCD
- Upgrade to 4-head
- Rotary axis
- Auto-focus Z-axis
- Extended-warranty pack
Standard Accessories Catalog Full reference: components included with every KASU machine, lifetime & replacement info. View catalog → All Optional Upgrades Rotary axes, CCD vision, auto-focus heads, multi-head configs, hot iron, 5-axis — compatibility & capex. Explore upgrades → KASU Shanghai HQ & Suzhou Factory 100+ models, 9 series, ISO 9001 / CE / FDA, 5,000+ customers in 80+ countries. See our factory →
Inside the KD1814-S2 Double Head Laser Cutter With Camera — Vision-Aided Engineering Highlights
The blocks below take you inside the KD1814-S2 Double Head Laser Cutter With Camera — each illustrates one specific camera, optics, motion or software component that defines vision-aided cutting accuracy. Topic-by-topic below: Smart Top Vision and Control Software, Auto Feeding Conveyor Table, and More Stable Triangle Structure Design.
Smart Top Vision and Control Software
KASU owns the full property of the large vision software system. The vision software of the KD1814-S2 camera laser cutting machine is used in conjunction with an industrial camera to automate the entire graphic inspection and position cutting process.
And our control software supports two laser heads in a single guide rail to help each other cut out all the printed patterns. The effective cutting width of the KD1814-S2 laser under vision mode can be 1800mm.
Auto Feeding Conveyor Table
KD1814-S2 is equipped with a chain conveyor belt, which can auto-feed the roll material right after the laser cutting process. With the optional active feeder, the operator only needs to take care of the cut pattern pick-up job.
More Stable Triangle Structure Design
The triangle machine structure design means more cost for us, but more benefits for you. Bigger waste collection space, better smoke exhausting effect and more stable for the conveyor chain belt’s motion.
One Stop Laser Solution For Your Product
Request An Instant Quote For Your Industry
How KASU Support Your Business
Our machines have ultra-high power capability, high-precision, and are durable.
We have a professional team that provides 100% after-sale support. We are dedicated to producing high-standard laser cutting machines worldwide. Full customization of machines according to your needs. KASU Laser is an ISO 9001 and ISO 14001 certified company in China.
Frequently Asked Questions About the KD1814-S2 Double Head Vision Laser Cutter
How do the two heads on the KD1814-S2 coordinate to cut printed patterns in parallel?
After the top camera scans printed registration marks across the 1800 × 1400 mm bed, KASU vision software splits the cut workload between the two heads — typically each head handles one half of the bed, optimising travel distance. Both heads can cut simultaneously if patterns are non-overlapping (which is the normal case for nested print sheets), delivering close to 2× throughput of the single-head S1 on identical printed jobs.
When does the KD1814-S2 dual-head cutting beat a roll-to-roll cutter for printed fabric?
The S2 wins when (a) print sheets are pre-cut to manageable size before cutting (typical for printed cardboard, printed leather, printed paper) and (b) you don’t want continuous roll handling (storage, take-up, downstream sorting). For continuous roll printed fabric workflows, a roll-to-roll KD-series (or the K1814-SY) is more efficient. For sheet-stock printed work at production volume, the KD1814-S2 dual-head wins.
Which printed-cardboard and label-converter operations in 2025 are KD1814-S2 power users?
Strongest current segments: US and German printed-cardboard packaging prototypers (mid-volume die-cut sample production); UK and Polish label converters; Indian printed-paper-bag manufacturers for European fashion brands; Brazilian printed-cosmetics packaging shops; and Australian and NZ printed-craft-supplies converters. All run sheet-stock printed material at the 200-500 sheets/day band where dual-head doubles output.
What's the realistic throughput on the KD1814-S2 for printed-cardboard die-cut prototyping?
Indicative numbers from KASU customer reports on 3 mm corrugated printed cardboard, simple rectangle-with-corner-radius shapes, 4 per A2 sheet: ~120 sheets per hour (= 480 die-cut prototypes per hour). On more complex shapes (cosmetics-packaging clamshells, with internal cutouts and creases): ~60 sheets per hour. The dual-head’s productivity uplift is most visible on simple high-copy-count patterns; complex shapes spend more time travelling between cut features and gain less from the second head.
What add-ons are standard on the KD1814-S2 versus optional?
| Item | Status |
|---|---|
| Dual cutting heads | Standard |
| Top vision camera (5 MP) | Standard |
| 5800 water chiller | Standard |
| KASU vision software | Standard (no licence fee) |
| Honeycomb table | Standard |
| Conveyor feeder | Optional (specify at order) |
| Upgraded 8 MP camera | Optional |
| External fume extractor | Optional (recommended) |
| Rotary axis | Optional |
