KX1810-F2 CCD Laser Cutter With Fixed Table
Co2 laser cutters are famous for their versatility, but they are also known as one of today’s most precise and accurate cutting tools. Adding a CCD camera to laser cutters makes it the ideal cutting tool to work on printed or embroidered patches, labels, and appliques.
- Extreme Cutting Versatility
- Powerful CCD Vision Software Meet Multi Industry Needs
- Vison and Non Vision Working Modes
- Super Low Machine Investment
- 🚚 7–15 days lead time
- 🛡 12-month warranty
High Cutting Precision
Hot Sealed Smooth Cutting Edge
Any Type of Textiles
Vision & Non-Vision Working Modes
See the KX1810-F2 CCD Laser Cutter With Fixed Table in Action — Vision-Aided Cutting Video
Watch the KX1810-F2 CCD Laser Cutter With Fixed Table run a real vision-aided cutting job on our factory floor — camera registration, smart path correction, and continuous output captured at production speed. The clip shows what to expect on day one before you commit to a machine of this class.
See the KX1810-F2 CCD Laser Cutter With Fixed Table in Action — Vision-Aided Cutting Video
The KX1810-F2 CCD Laser Cutter is the Co2 laser cutter combined with the smart CCD vision software and camera. It can detect features of the small-sized printed or embroidered fabrics, leather, and other flexible materials and then position cut with high accuracy.
When under the non-vision cutting mode, the two heads of KASU KX1810-F2 laser cutter can simultaneously cut the same shapes of patterns in plain fabrics.
KX1810-F2 CCD Laser Cutter With Fixed Table — Vision System Specs, Accessories & Manufacturing
Every vision system, optics and motion dimension of the KX1810-F2 CCD Laser Cutter With Fixed Table in one place — complete technical data sheet, included accessories, available optional upgrades, and our factory manufacturing process. Key strengths at a glance: High Cutting Precision, Hot Sealed Smooth Cutting Edge, and Any Type of Textiles. Switch the tabs below to drill into each.
- Data Sheet
- Includes & Options
- Video Testimonials
| Working Area | 1800MM*1000MM | Software | KASU |
| Laser Type | Glass CO2 Laser Tube | Working Speed | <1000 MM/S |
| Laser Power | 80/100/130/150W | Power Supply Requirements | AC220V±5% 50Hz/60Hz 1Phase |
| Heads of Laser | Double Heads | Format Supported | AI\BMP\PLT\DXF\DST |
| Dimensions with Wood Package | 1.9*2.5*1.32M | Positioning Accuracy | ±0.1MM |
| Gross Weight | 700KG | Operating Temperature | minus 10℃~45℃ |
| Motion System | Stepping Motor | Operating Humidity | 5-95% |
| Cooling System | 5200 Industrial Water Chiller | Total Power | <1.5KW (Excluding exhauster) |
What's Included with the KX1810-F2 CCD Laser Cutter With Fixed Table
- 2× Glass CO2 laser tubes — 80W / 100W / 130W
- 2× independent cutting heads on shared gantry
- Side-mount CCD vision camera
- Fixed cutting table
- HIWIN-spec linear rails for 1800 × 1000 mm bed
- 2× ZnSe focusing lenses
- 2× three-mirror reflective sets
- Industrial water chiller (2-tube)
- Industrial oil-free air pump (2-line)
- 1.5kW centrifugal smoke exhaust + ducting kit
- Industrial DC HV power supply
- Triangle-truss welded steel frame
- Vision software
- E-stop + tower light
- Multi-language CE laser warning labels
- Factory tool kit
Compatible Upgrades for the KX1810-F2 CCD Laser Cutter With Fixed Table
- Upgrade to top-mount CCD
- Upgrade to 4-head (KX1810-F4)
- Rotary axis
- Auto-focus Z-axis (each head)
- Extended-warranty pack
Standard Accessories Catalog Full reference: components included with every KASU machine, lifetime & replacement info. View catalog → All Optional Upgrades Rotary axes, CCD vision, auto-focus heads, multi-head configs, hot iron, 5-axis — compatibility & capex. Explore upgrades → KASU Shanghai HQ & Suzhou Factory 100+ models, 9 series, ISO 9001 / CE / FDA, 5,000+ customers in 80+ countries. See our factory →
Racing suit cutting
Inside the KX1810-F2 CCD Laser Cutter With Fixed Table — Vision-Aided Engineering Highlights
The blocks below take you inside the KX1810-F2 CCD Laser Cutter With Fixed Table — each illustrates one specific camera, optics, motion or software component that defines vision-aided cutting accuracy. Topic-by-topic below: CCD Industrial Camera System, Smart CCD Vision Software, and Honeycomb Table With Strong Support.
CCD Industrial Camera System
With the assistance of the industrial 130-mega-pixels CCD camera, KASU KX1810-F2 CCD can have a very high cutting precision when cutting small-sized printed or embroidered patterns (better within 15cm) at an affordable price.
Smart CCD Vision Software
KX1810-F2 can work under both vision and non-vision modes. When under the vision modes, all you need to do is create the template according to the features of the graphics, set the cutting area, and then the vision software will start taking photos and generate a cutting path with high precision.
Honeycomb Table With Strong Support
KX1810-F2 model is equipped with the honeycomb working table, which can give the soft textiles strong support and good cutting edge. Together with the well-designed smoke exhausting system, the laser beam will leave no black or yellow marks along the fabric edge.
One Stop Laser Solution For Your Product
Request An Instant Quote For Your Industry
How KASU Support Your Business
KASU Laser has unique R&D, production, and manufacturing technology of laser cutting machines. We are a competent manufacturer in China who deliver the highest quality machines. Comprehensive support, OEM / ODM services, and 24-hour stable-running intelligent laser cutters.
Please get in touch now!
Frequently Asked Questions About the KX1810-F2 CCD Laser Cutter with Fixed Table
What does "fixed table" mean on the KX1810-F2, and why pick it over a honeycomb-table model?
The fixed table is a flat, non-removable cutting surface (typically aluminium grid or solid steel) instead of the removable honeycomb. Benefits: (1) consistent flatness across the full 1800 × 1000 mm bed (honeycomb can sag slightly over time), (2) easier cleaning (no honeycomb cells to vacuum out), (3) better suited to vacuum-clamp setups that need a flat surface. Trade-off: thin paper-and-fabric cutting suffers without honeycomb’s air gap underneath — the fixed table reflects more energy back, increasing scorching risk.
Which CCD-printed material workflows are best matched to the KX1810-F2 fixed-table format?
Strongest fit: cut-and-pack workflows on heavier substrates (printed cardboard 3-5 mm, printed PU leather, printed corrugated, printed felt 8 mm+) where the material is rigid enough to lie flat on the fixed table without honeycomb support. Less ideal for: thin printed paper, thin printed fabric, or any sub-1mm printed substrate — those benefit from honeycomb’s anti-scorch air gap.
Which 2025 industries are adopting the KX1810-F2 fixed-table CCD vision configuration?
Current top buyers: US and EU printed-corrugated packaging prototypers; German printed-fabric-laminate shops; Italian printed-faux-leather accessory makers; UK printed-felt-promotional-product converters; and Australian printed-rigid-display makers. Shared workflow signal: substrate is rigid enough not to need honeycomb, dominant volume is mid-thickness printed sheet stock.
Can the KX1810-F2's fixed table be retrofitted with a honeycomb insert for mixed workloads?
Yes — KASU offers a removable honeycomb insert that drops onto the fixed table for jobs requiring honeycomb support (thin paper, fabric). Mode switching takes about 2 minutes (lift the honeycomb out / drop it back in). This makes the KX1810-F2 a flexible cutter for shops that primarily run rigid printed work but occasionally need honeycomb support for one-off thin-substrate jobs.
How does the KX1810-F2 compare to the KX1325-F (vision flatbed) for printed-cardboard prototyping?
| Spec | KX1810-F2 fixed | KX1325-F flatbed |
|---|---|---|
| Working area | 1800 × 1000 mm | 1300 × 2500 mm |
| Table type | Fixed (flat) | Flatbed (honeycomb option) |
| Best sheet aspect | Wide and short | Narrow and long |
| Vision area | Full bed | Full bed |
| Price band | Mid vision | Entry vision flatbed |
