KD1814-SY-C Vision Laser Cutting Machine With Safe Cover
KASU KD1814-SY-C double asynchronous laser cutting heads are installed in two separate guide rails, cutting different shapes of patterns. It supports continuous joint cutting of oversized patterns over 1400mm in length. And the all-around safety cover model is specially designed to meet the government requirements for plant safety.
- All-Round Safe Cover Meet Compliance Requirements
- Doubled Cutting Efficiency, Higher Productivity
- Powerful Vision Software Automate Your Factory
- Both Vison and Non-Vision Working Modes
- Low Initial Machine Investment, More Profits
- 🚚 7–15 days lead time
- 🛡 12-month warranty
High Cutting Precision
Hot Sealed Cutting Edge
Any Type of Textiles
Continuous Working Mode
See the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover in Action — Vision-Aided Cutting Video
Watch the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover run a real vision-aided cutting job on our factory floor — camera registration, smart path correction, and continuous output captured at production speed. The clip shows what to expect on day one before you commit to a machine of this class.
See the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover in Action — Vision-Aided Cutting Video
The KD1814-SY-C Vision Laser Cutting Machine With Safe Cover is the laser cutting machine combined with the advanced top vision software system of the KASU laser.
It supports one-time cutting of plain fabrics with 1800*1400mm under non-vision working mode and 1800*1200mm under vision working mode. It can automatically recognize the contour of the printed or embroidered fabrics, leather, and other flexible materials and then cut with super high accuracy and efficiency.
KD1814-SY-C Vision Laser Cutting Machine With Safe Cover — Vision System Specs, Accessories & Manufacturing
Every vision system, optics and motion dimension of the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover in one place — complete technical data sheet, included accessories, available optional upgrades, and our factory manufacturing process. Key strengths at a glance: High Cutting Precision, Hot Sealed Cutting Edge, and Any Type of Textiles. Switch the tabs below to drill into each.
- Data Sheet
- Includes & Options
- Video Testimonials
| Working Area | 1800MM*1200MM Vision Mode 1800MM*1400MM Non-Vision Mode | Software | KASU |
| Laser Type | Glass CO2 Laser Tube | Working Speed | <1000 MM/S |
| Laser Power | 80/100/130/150W | Power Supply Requirements | AC220V±5% 50Hz/60Hz 1Phase |
| Heads of Laser | Dual Heads | Format Supported | AI\BMP\PLT\DXF\DST |
| Dimensions with Wood Package | 2.28*2.5*2.14M 2.24*1.55*1.16M | Positioning Accuracy | ±0.1MM |
| Gross Weight | 1450KG | Operating Temperature | minus 10℃~45℃ |
| Motion System | Stepping Motor | Operating Humidity | 5-95% |
| Cooling System | 5200 Industrial Water Chiller | Total Power | <1.5KW (Excluding exhauster) |
What's Included with the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover
- Glass CO2 laser tube — 80W / 100W / 130W
- Top-mounted CCD vision camera (5MP)
- Full safety cover (Class 1 enclosed laser product — FDA-compliant)
- HIWIN-spec linear rails for 1800 × 1400 mm bed
- American II–VI 25mm focusing lens
- Three molybdenum reflective mirrors
- S&A CW-5200 industrial chiller
- Hailey diaphragm air pump
- 1.5kW centrifugal smoke exhaust + ducting kit
- Industrial DC HV power supply
- Triangle-truss steel frame + safety cover
- Vision software
- Door interlock + E-stop + tower light
- Multi-language CE laser warning labels (Class 1 set)
- Factory tool kit
Compatible Upgrades for the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover
- Rotary axis
- Auto-focus Z-axis
- Upgrade to 4-head with safe cover
- Extended-warranty pack
Standard Accessories Catalog Full reference: components included with every KASU machine, lifetime & replacement info. View catalog → All Optional Upgrades Rotary axes, CCD vision, auto-focus heads, multi-head configs, hot iron, 5-axis — compatibility & capex. Explore upgrades → KASU Shanghai HQ & Suzhou Factory 100+ models, 9 series, ISO 9001 / CE / FDA, 5,000+ customers in 80+ countries. See our factory →
Inside the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover — Vision-Aided Engineering Highlights
The blocks below take you inside the KD1814-SY-C Vision Laser Cutting Machine With Safe Cover — each illustrates one specific camera, optics, motion or software component that defines vision-aided cutting accuracy. Topic-by-topic below: Self-Owned Top Vision Software System, Dual Heads With Dual Guiderails, and All-Round Safe Cover.
Self-Owned Top Vision Software System
KASU owns the full property of the large vision software system. The vision software of the KD1814-SY-C camera laser cutting machine is used in conjunction with an industrial camera to automate the entire graphic inspection and position cutting process.
Dual Heads With Dual Guiderails
Unlike the dual heads with a single guide rail model, the innovative invention of KD1814-SY ensures the two heads of the camera laser cutter can cut either the same or different designed patterns at the same time. When compared with the single head model, the dual guide rail model has much higher productivity, especially when cutting small-sized patterns.
All-Round Safe Cover
We designed this specialized model based on some clients’ government compliance requirements. The all-round safe cover can enclose the whole cutting range. The laser cutter will stop the laser cutting head immediately if the cover is opened.
One Stop Laser Solution For Your Product
Request An Instant Quote For Your Industry
How KASU Support Your Business
Contact us! We have our own R&D center in line with international standards, strong R&D technicians, and 70+ vision software and laser machine intelligent properties and patents.
Our design team can also tailor machine models to your specific industry requirements, fast lead time nad delivery, and 24/7 online support. KASU Laser is a trusted laser cutting machine provider in China.
Frequently Asked Questions About the KD1814-SY-C Enclosed Vision Laser Cutter
What does "safe cover" mean on the KD1814-SY-C, and why does it matter for production environments?
The KD1814-SY-C is fully enclosed in a metal-and-acrylic cabin around the entire cutting bed. The cabin contains all laser energy (Class 1 enclosure under EN 60825-1), prevents accidental operator exposure, and contains particulates and fumes for cleaner extraction. For high-volume factory environments — where the machine runs 16+ hours/day with rotating operators and Health & Safety inspectors visit regularly — the enclosed cabin is often a regulatory requirement, especially in EU and UK facilities.
How does the enclosed cabin affect operator interaction and material loading?
The cabin has a large interlocked top door for material loading. Opening the door pauses the laser instantly (safety interlock); closing it resumes. Loading a fresh printed sheet adds ~3-5 seconds per cycle versus an open-bed cutter — typically a fair trade for the safety-and-fume containment benefits. The camera operates through a clear-acrylic viewing window in the top door, so vision registration is unaffected.
Which European and UK regulatory standards does the KD1814-SY-C comply with?
| Standard | Coverage |
|---|---|
| CE (EU) | Electrical, EMC, mechanical safety |
| EN 60825-1 | Laser safety Class 1 enclosure |
| FDA 21 CFR 1040.10 | US laser product safety |
| HSE (UK) | Workplace machinery enclosure guidance |
| AS/NZS 2211 (AU/NZ) | Laser safety reference |
Documentation pack ships with the machine — no need to procure third-party certification.
Which industries in Germany, Italy, and the UK choose the safe-cover variant over the open-bed KD1814-SY?
Heavily preferred by: German printed-packaging factories (worker council requirements), UK label converters working in shared-tenancy industrial estates (cross-tenant fume containment), Italian fashion-accessory printers (cleaner factory floors for visiting brand auditors), French printed-textile mills (occupational safety inspections), and Scandinavian printed-product shops (high baseline workplace-safety standards). The safe-cover premium is typically 15-20% over the open-bed model.
What's the recommended ventilation setup for the KD1814-SY-C enclosed cabin?
The cabin has a built-in exhaust port (standard 150 mm ducting) that connects to either: (1) a recirculating activated-carbon filter unit (best for confined-space installations), (2) an external duct vented to outside (best for raw extraction), or (3) a centralised factory fume-extraction system (best for multi-machine installations). KASU recommends a minimum 800 m³/h extraction rate for continuous 130 W tube operation — adequate to keep cabin interior below visible smoke even on heavily-smoking material like MDF or thick PU leather.
