KC-600 3D Auto Focus Laser Cutting Machine
KC-600 3D Auto Focus Laser Cutting Machine has high quality, sealed dustproof design, aperture 30mm galvo head 3-axis dynamic focus large processing range engraving and cutting 600*600mm large processing range. Anti-interference isolation design. Compact structure and beautiful appearance, modular design of the device. Simple wiring, integrated design easy after sale and maintenance, all devices are connected by connectors, quickly change devices is possible.
- The latest 3D dynamic focusing galvanometer system
- High Accuracy and Precision Cuts
- Super Low Machine Investment
- Computer-Aided Manufacturing
- 🚚 7–15 days lead time
- 🛡 12-month warranty
See the KC-600 3D Auto Focus Laser Cutting Machine in Action — 3D Motion Demo Video
Watch the KC-600 3D Auto Focus Laser Cutting Machine run a real 3D cutting job on our factory floor — multi-axis motion, surface tracking, and dynamic focus captured at production speed. The clip shows what to expect on day one before you commit to a machine of this class.
See the KC-600 3D Auto Focus Laser Cutting Machine in Action — 3D Motion Demo Video
The 3D Auto Focus CO2 Laser Cutting Machine has a larger effective processing range than the ordinary marking machine, and has a more detailed processing effect in the same range.
The latest 3D dynamic focusing galvanometer system and software allows the entire machine to support indiscriminate cutting and surface marking for height differences of up to 20 centimeters, and up to 85 degree angles for near vertical slopes. For example, if it is used to cut bra cups, 700 pieces can be produced per hour.
KC-600 3D Auto Focus Laser Cutting Machine — 3D Motion Specs, Optical Setup & Manufacturing
Every 3D motion, optics and process dimension of the KC-600 3D Auto Focus Laser Cutting Machine in one place — complete technical data sheet, included accessories, available optional upgrades, and our factory manufacturing process. Key strengths at a glance: High Processing Speed, High Quality, and Good Cutting Effect. Switch the tabs below to drill into each.
- Data Sheet
- Includes & Options
| Working Area | 600mm*600mm | Software | 3D LASER |
| Laser Type | Glass CO2 Laser Tube | Laser Power | 100W |
| Galvo Head | Aperture: 30mm | Power Supply Requirements | AC110V~220V±5% 50Hz/60Hz 1Phase |
| Laser Wavelength | 10640nm | Pulse Frequency | 0-130Khz |
| Dimensions | 2330 X 900 X1450mm | Spot Size | 0.27mm(600x600mm) |
| Net Weight | 180KG | Computer | KASU Customized |
| Working Mode | XYZ 3 Axis Dynamic Focus System | Operating Humidity | 5-95% |
| Cooling System | 5000 Industrial Water Chiller | Total Power | 1KW |
What's Included with the KC-600 3D Auto Focus Laser Cutting Machine
- Glass CO2 laser tube — 80W / 100W (configurable)
- 3D auto-focus servo head (real-time Z tracking)
- HIWIN-spec linear rails for 600 × 400 mm bed
- American II–VI 25mm focusing lens
- Three molybdenum reflective mirrors
- S&A CW-3000 industrial chiller
- Hailey diaphragm air pump
- Compact centrifugal smoke exhaust + ducting kit
- Industrial DC HV power supply
- Triangle-truss steel frame (compact)
- 3D AF software (auto-scan + real-time modes)
- E-stop + tower light
- Multi-language CE laser warning labels
- Factory tool kit
Compatible Upgrades for the KC-600 3D Auto Focus Laser Cutting Machine
- Rotary axis (φ80 — sized for compact bed)
- Extended Z-range AF head
- Blade knife table swap
- Extended-warranty pack
Inside the KC-600 3D Auto Focus Laser Cutting Machine — 3D Motion Engineering Highlights
The blocks below take you inside the KC-600 3D Auto Focus Laser Cutting Machine — each illustrates one specific axis, optical system or process component that defines its 3D motion envelope and surface tracking. Topic-by-topic below: High Quality Galvo Head, Super Fine Spot Size, and Large Processing Range.
High Quality Galvo Head
2.5-inch high-speed scanning galvanometer system can greatly enhance the engraving effect.
Minimum line width： 0.35mm（500mm area)
Available process types:
- Marking
- Cutting
- Perforating
Super Fine Spot Size
Compared with ordinary glass tubes, the super glass tube marking machine has finer spot size and can achieve the fineness of the glass tube equivalent to the 400mm range in the range of 600mm.
The line width of Super glass tube in the range 500x500mm is 0.35mm
The line width of Super glass tube in the range 300x300mm is 0.18mm
Large Processing Range
Kasu 3D Auto Focus Laser Cutting Machines have a number of different table sizes to choose from depending on cutting needs. Largest available range：600*600mm
Optional range：
①300*300mm (Focus 366)
②400*400mm (Focus 466)
③500*500mm (Focus 566)
④600*600mm (Focus 676)
One Stop Laser Solution For Your Product
Request An Instant Quote For Your Industry
Advantages of KASU Laser
We provide better after-sales service with quick response and comprehensive technical support to ensure that your equipment is always in the best condition. In addition, we customize our solutions to meet a variety of complex application scenarios. Choose Kasu Laser, choose excellent quality and worry-free service. Choosing a machine from Kasu Laser is a wise decision.
Frequently Asked Questions About the KC-600 3D Auto Focus Laser Cutting Machine
What is 3D auto-focus, and how is it different from a 5-axis cutter?
3D auto-focus means the laser head’s Z-axis (height) adjusts dynamically to match the workpiece’s surface profile â handling uneven, stepped, or slightly-warped flat stock. 5-axis (like the KA5-080602) adds two rotational axes for cutting on truly 3D contoured shapes (helmets, dome panels). 3D auto-focus is for variable-height FLAT stock; 5-axis is for genuinely 3D curved surfaces. The KC-600 fits the 3D auto-focus niche.
Which uneven-surface workpieces is the KC-600 designed for?
Sweet spot: warped MDF / plywood (industrial-grade hardwood that doesn’t lay flat), pre-formed plastic enclosure tops, embroidered patches with raised stitching (1-3 mm height variation), stepped electronics housings, leather hides with natural surface variation, and laminated multi-layer composites. The KC-600 tracks the surface in real time so the cut always lands at the correct focal depth.
What's the working area on the KC-600, and what's its target market?
KC-600 has a 600 Ã 400 mm bed â compact enough for prototyping / sampling shops, large enough for typical electronics enclosures and small consumer-product trimming. 2025 export segments: German prototyping bureaus (electronics enclosures), Italian sample-shop furniture makers (warped wood test cuts), and Korean / Japanese precision-craft studios where standard flat-bed lasers miss the surface variation.
How fast does the KC-600 auto-focus servo respond to surface changes?
The auto-focus Z-axis servo responds in ~15 ms â fast enough to track normal surface variation at cutting speeds up to 600 mm/s. For very rapid surface changes (e.g., 3 mm height jump within 50 mm horizontal distance), the cutter automatically slows to maintain track. Practical sweet spot: â¤500 mm/s on highly variable surfaces, full speed on slowly-varying.
What software workflow handles the 3D surface data?
Two modes: (1) Auto-scan mode: before cutting, the laser head scans the workpiece surface (~30 sec for a 400 Ã 300 mm area), builds a height map, then cuts with continuous AF following that map. (2) Real-time mode: the AF sensor tracks live during cutting â no pre-scan, but cut speed is capped to ~500 mm/s. For consistent material (same warped MDF stock every time), auto-scan saves time. For one-off variable workpieces, real-time is more flexible.
